HELITRONIC DIAMOND
The WALTER HELITRONIC DIAMOND machine family represents a line of advanced erosion grinding machines. These machines are ideally suited for high-precision grinding of complex geometries in the aerospace, medical, and tooling industries, where exceptional surface finish and accuracy are critical. Key benefits include the ability to achieve extremely fine tolerances and superior surface quality through advanced erosion techniques and sophisticated control systems.
Key Features of the HELITRONIC DIAMOND:
Superior surface finishes.
High precision eroding.
Efficient diamond grinding.
Long tool life.
Compare the specifications of the different models available in the HELITRONIC DIAMOND.
| Specifications | HELITRONIC RAPTOR DIAMOND | HELITRONIC DIAMOND EVOLUTION | HELITRONIC POWER DIAMOND 400 | HELITRONIC VISION DIAMOND 400 L |
|---|---|---|---|---|
| Max. Travel X | 460 mm | 320 mm | 650 mm | 500 mm |
| Max. Travel Speed X | 15000 mm/min | 15.000 mm/min | 15.000 mm/min | 50.000 mm/min |
| Max. Travel Y | 320 mm | 200 mm | 350 mm | 350 mm |
| Max. Travel Speed Y | 15000 mm/min | 15.000 mm/min | 15.000 mm/min | 50.000 mm/min |
| Max. Travel Z | 660 mm | 470 mm | 720 mm | 700 mm |
| Max. Travel Speed Z | 15,000 mm/min | 15.000 mm/min | 15.000 mm/min | 50.000 mm/min |
| Max. Spindle Power | 11,5 kW | 9 kW | 24 kW | 35 kW |
| Max. Number Of Revolutions | 10.500 /min | 10.500 /min | 7.000 / 10.000 /min | 7.800 / 10.000 /min |
| Max. Grinding Wheel Diameter | 200 mm | 150 mm | 254 mm | 254 mm |
| Workpiece Length | 270 (350) mm | 255 mm | 520 mm | 420 mm |
| Workpiece Diameter | 3 - 290 (400) mm | 1 - 165 mm | 3 - 380 mm | 3 - 315 mm |
| Max. Workpiece Weight | 50 kg | 30 kg | 50 kg | 50 kg |
| Swiveling Range A | - | ∞ ° | ∞ ° | ∞ ° |
| Swiveling Range C | - | 200 ° | 200 ° | 200 ° |
| Specifications | HELITRONIC RAPTOR DIAMOND | HELITRONIC DIAMOND EVOLUTION | HELITRONIC POWER DIAMOND 400 | HELITRONIC VISION DIAMOND 400 L |
|---|---|---|---|---|
| Max. Travel X | 460 mm | 320 mm | 650 mm | 500 mm |
| Max. Travel Speed X | 15000 mm/min | 15.000 mm/min | 15.000 mm/min | 50.000 mm/min |
| Max. Travel Y | 320 mm | 200 mm | 350 mm | 350 mm |
| Max. Travel Speed Y | 15000 mm/min | 15.000 mm/min | 15.000 mm/min | 50.000 mm/min |
| Max. Travel Z | 660 mm | 470 mm | 720 mm | 700 mm |
| Max. Travel Speed Z | 15,000 mm/min | 15.000 mm/min | 15.000 mm/min | 50.000 mm/min |
| Max. Spindle Power | 11,5 kW | 9 kW | 24 kW | 35 kW |
| Max. Number Of Revolutions | 10.500 /min | 10.500 /min | 7.000 / 10.000 /min | 7.800 / 10.000 /min |
| Max. Grinding Wheel Diameter | 200 mm | 150 mm | 254 mm | 254 mm |
| Workpiece Length | 270 (350) mm | 255 mm | 520 mm | 420 mm |
| Workpiece Diameter | 3 - 290 (400) mm | 1 - 165 mm | 3 - 380 mm | 3 - 315 mm |
| Max. Workpiece Weight | 50 kg | 30 kg | 50 kg | 50 kg |
| Swiveling Range A | - | ∞ ° | ∞ ° | ∞ ° |
| Swiveling Range C | - | 200 ° | 200 ° | 200 ° |
Access detailed specifications, features, and technical drawings for the HELITRONIC DIAMOND. Please provide your name and email to receive the brochure(s) via email.
